Ideal for low-energy consumption construction (BBC), RT2012 or RE2020. The unit is equipped with a central fresh air input on a connection nozzle:
* no air intake in the room,
* direct connection possible to crawl space or external air intake.
Also called the suction exhaust, zone 3 installation does not require an existing chimney flue. The smoke exhaust tubing horizontally to the front. This installation configuration requires a concentric flue and professional advice. Only sealed wood pellet stoves certified by CSTB can be installed in zone 3.
The KCC is used to adapt the unit to the specifications for wood pellets, such as: the type of installation, altitude, the type of soiling caused by the burner and heat exchanger, to ensure more efficient and better performance over time and to reduce maintenance.
The CSTB technical assessment (the French scientific and technical construction center) officially certifies the seal on wood pellet stoves. n°14.2/15-2130*V5
For pellet appliances, the 1-year warranty extension is conditional on the is conditional on the product being registered online.
*DAY: The unit has 2 daily programs so it can turn on and off twice per day
*WEEK: the unit has 4 weekly programs so that you can program it to turn on and off 4 times per day, every day of the week.
*WEEKEND: the unit has 2 programs for the weekend (Saturday, Sunday), which enable it to turn on and off twice per day
Air distribution connection lines are available as an option. Reference P690080: kit 2 connection lines & screws.
Possibility of connecting an optional Wifi kit to the pellet stove to control it remotely, from a mobile device.
*Adjust operating power: 5 pre-programmed power settings managed automatically.
*Adjust the preset temperature: you choose the desired ambiant temperature in the room. It is measured using a wire probe. The wood pellet stove adjusts its power to reach and maintain the requested value.
Standby is a backup feature of the device. The unit turns off if the room temperature is 3°C higher than the temperature set for over 60 seconds. The unit turns on again when the room temperature drops 1°C below the temperature set.
A tangential forced convection ventilator is used. It distributes the hot air inside the room.
